Fixed Regeneration Annex QCR Series-Fujian quancheng machinery Co.,Ltd.

Product Description The QCR floor-type retrofit equipment series is a practical, flexible, simple and quality-guaranteed asphalt pavement recycling technology equipment. The old asphalt layer is recovered by the milling machine and returned to the mixing field. According to the quality requirements of different levels of the road surface, the proportion of the old asphalt mixture that can be added in the mixing ratio is determined, and the old asphalt mixture after the screening is flow-typed. The reclaimed asphalt material is heated to the required temperature by the second drying drum, and then the hot material is metered and transported, and the new aggregate, the new asphalt, the new ore powder is stirred into a quality asphalt concrete, and then transported to the quality. Ground paving and rolling.

Technical Parameter （Swipe left to see more）

Model		QCR600	QCR800	QCR1000	QCR1500	QCR2000
Production capacity (t/h) standard conditions		50	65	80	120	160
Machine power (KW)		160	180	195	270	302
Maximum addition amount (kg/batch)		600	800	1000	1500	2000
Thermal storage capacity (t)		8	8	10	10	12
Add specification material (mm)		0~13 13~25
Fuel consumption (kg/t finished material)		≤5.5~7.0
Measurement accuracy	Static	Recycled material ≤±0.5% Additive ≤±0.2 %
Measurement accuracy	Dynamic	Recycled material ≤±2% Additive ≤±1.0%
Control method		Independent electronic control system seamlessly connected with the original unit
Ambient noise (Db)		≤80
Can be matched with native /> Unit type and most Large addition ratio	QC1000	50%	——	——	——	——
	QC1500	40%	50%	——	——	——
	QC2000	30%	33%	50%	——	——
	QC3000	——	25%	33%	50%	67%
	QC4000	——	——	25%	37.5%	50%
